UQ-20 Underground Mining Truck With Automatic Ride Control And Declutch

Name: UQ20 Underground Mining Truck With Automatic Ride Control And Declutch
Brand: Beijun
Price: 1 USD

China UQ-20 Underground Mining Truck With Automatic Ride Control And Declutch wholesale

Brand Name : Beijun

Model Number : UQ-20

Certification : CE,ISO

Place of Origin : China

MOQ : 1

Payment Terms : L/C, T/T

Supply Ability : 1000 Set/Sets per Month

Delivery Time : 6-15 days

Packaging Details : Customized packaging

Engine Model : YUCHAI Engine with Turbocharge

Engine Power : 290HP

Transmission Model : FASITE 9JS118

Drive Mode : 4x2

Dimension of Bottom Spring Plate : Length 90mm, Width 16mm

Cabin : Canopy

Type of Bucket : U type

Fuel type : Diesel

Condition : New

Contact Now

Product parameters of 20Ton Underground Mining Dump Truck

If the mining four-wheeled vehicle has not been used for more than half a month, the engine must be started once every 15 days and run for a period of time to charge the battery; if the shutdown time exceeds one month, please remove the battery and charge it with a charger. It is necessary to properly move the mining four-wheeled vehicle to change the pressure-receiving part of the tire to prevent the tire from being deformed; if the vehicle needs to be parked for more than two months, the battery negative pole must be disconnected or removed. In cold regions, the fuel should be -35# light diesel oil, and the engine oil of diesel engine should be CF grade. When the temperature is below 0 °C, the antifreeze concentration should be checked regularly, and untreated water is prohibited as the engine coolant.

Model	UQ-20
Engine Model	YUCHAI Engine with Turbocharge
Engine Power	290HP
Total Dimension	620024002450mm
Transmission Model	FASITE 9JS118
Transmission Gear	8 Forward Gear, 1Back Gear,Rear High Speed Controller
Drive Mode	4x2
Front Axle Model	Styer Axle
Rear Axle Model	Styer Axle
Tire Model	10.00-20 Radial steel tire, Rear Double Tyre One Side,
No.of Bottom Spring Plate	Front 11 PCS, Rear 12 PCS
Dimension of Bottom Spring Plate	Length 90mm, Width 16mm
Size of the Bucket:Length×width×height	4500mm2400mm1000mm
Type of Bucket	U- Type
Thickness of Bucket Steel Plate	bottom 10mm side 8mm
Unloading Type	Hydraulic Double Top Dump
Steering Type	Hydraulic power steering
Braking Type	Air Brake
Cabin	Canopy
Driving Position	Left Hand Drive
Cooling sytem	Standard Water Cooling System
Loading Capacity	20 Tons
