Product parameters of 3 Ton Dump Truck
From design to production, they must consider adapting to the harsher environment. They are simple in appearance, easy to disassemble and repair, easy to assemble each assembly, strong engine power, long driving range, and can Various modifications, the most important thing is high reliability and durability. Only when these standards are met can they truly play a role in battlefields, prospecting, and rescue operations. Rockcrawling is an extreme form of off road driving. Drivers use vehicles anywhere from stock to highly modified to overcome obstacles (usually rocks). In rock crawling, drivers drive highly modified four-wheel drive vehicles such as trucks, Jeeps, and "buggies" over very harsh terrain. Driving locations include boulders, mountain foothills, rock piles, mountain trails, etc. Rock crawling is about slow-speed, careful driving. Rock crawlers often drive up, down and across obstacles that would appear impassable. Such vehicles to rock climb are primarily 4x4s.
Our company has solid technology, flawless inspection, advanced equipment, reliable quality and flexible modes of operation. What's more, we have obtained ISO9001 and CCC certificates (China Compulsory Certification). Yizhuan series trucks have occupied the interior market for many years and have procured remarkable achievements. Our survival is based on the quality. Credit standing is the guarantee of our success. We will endeavor to treat customers honestly, managing flexibly, guaranteeing high quality but low price, and keeping high efficiency. We promise that all the products that are adapted and sold by us can get one-year services and maintenance for the life. What's more, the service can be dealt with in 48 hours.
| Model | UQ-3 |
| Engine Model | CHANGCHAI 490 |
| Engine Power | 63 HP |
| Transmission Model | Ningjing 130 |
| Transmission Gear | 4 Forward Gear, 1Back Gear,Rear High Speed Controller |
| Drive Mode | 4x4 |
| Front Axle Model | CHITONG ISUZU Axle |
| Rear Axle Model | CHITONG ISUZU Axle |
| Tire Model | 700x16 Line Tire,
Rear Single Tyre One Side, |
| No.of Bottom Spring Plate | Front 7 PCS, Rear 8 PCS, Spare 6PCS |
| Dimension of Bottom Spring Plate | Length 70mm, Width 10mm |
| Size of the Bucket:Length×width×height | 2400mm*1300mm*450mm |
| Type of Bucket | U type Bucket |
| Thickness of Bucket Steel Plate | bottom 6mm side 4mm |
| Unloading Type | Hydraulic Double Top Dump |
| Steering Type | Hydraulic power steering |
| Braking Type | Air Brake |
| Cabin | Canopy |
| Driving Position | Left Hand Drive |
| Cooling sytem | Standard Water Cooling System |
| Loading Capacity | 3 Tons |
